Product Description
DMX Panel Light 300*300mm
1：DC24V 45W. IP20
2：led video panel led wall panel
3：DMX DJ booth panel DMX wall panel
4：Sound activated music controllable
5：Marix led light control solution
Detailed Specification:
| Parameters | Description: | |||||
| Product | 150*150mm | 150*150mm | 250*250mm | 300*300mm | 300*300mm | 600*600mm |
| Model No. | LW-DMXP-D150150-D3636 | LW-DMXP-D250250-D3601 | LW-DMXP-D250250-D1616 | LW-DMXP-D300300-D1616 | LW-DMXP-D300300-D144144 | LW-DMXP-D600600-D144144 |
| Dimension | 150*150mm | 150*150mm | 250*250mm | 300*300mm | 300*300mm | 600*600mm |
| LED QTY | 36pcs RGB SMD 5050 | 36pcs RGB SMD 5050 | 16pcs RGB SMD 5050 | 16pcs RGB SMD 5050 | 144pcs RGB SMD 5050 | 144pcs RGB SMD 5050 |
| Pixel QTY | 36 | 1 | 16 | 16 | 144 | 144 |
| Pixel Pitch | P25 | P25 | P62.5 | P75 | P22.5 | P45 |
| View Angle | 180° | 180° | 180° | 180° | 180° | 180° |
| Voltage | DC12/24V | DC12 | DC12/24V | DC12/24V | DC12/24V | DC12/24V |
| Max Power | 8W | 8.64W | 4.8W | 4.8W | 45W | 45W |
| PCB Color | White or Black | |||||
| PCB Type | Standard FR4 PCB Panel | |||||
| Color | RGB full color | |||||
| Protocol | DMX512 | |||||
| LED Source Life | 50'000 hours | |||||
| Protection | IP20 | |||||
| Working Tem. | -20°c to 50°c | |||||
